Marca | Warex |
Prodotto | DKZ103 <GS> DN 200 |
Descrizione | Valvola a farfalla |
Codice interno | PRT4487515 |
Codice doganale | 84818085 |
Specifiche tecniche | based on order 173179 / 2019 for medium: powder coating characteristics: chemical not aggressive, not sticky working pressure: pressureless max. allowable working pressure: < 0,5 bar (Ps) MAWP (note: MAWP = design pressure) max. allowable working temperature: 0 °C ... + 60 °C (Ts) MAWT Special equipment silicone free design Design of the valve with manual override on the blind side additional attachments: pneumatic actuator AT 220 DR double acting air supply necessary 6,0 bar ambient temp.: 0 °C ... + 50 °C (Ta) Ex-protection: II 1/3 D Ex h IIIC T85°C Da/Dc X Rating of butterfly-valves according PED/2014/68/EU, diagram 7 Certified module A2 The butterfly-valves are not subject to this conformity assessment Article number WX2000 face to face 54 mm for mounting between flanges, drilled according to EN 1092, PN 10 Butterfly valve explosion pressure proof and flame proof up to 10 ba acc. EC-type Examination BVS 19 ATEX H035X - as apparat (KST < 500 bar m/sec) test pressure: 13 bar for tightness body of Silumin with ground connection disc of stainless steel 1.4408 - polished Ra < 0,8μ - shaft of stainless steel stainless steel 1.4057 shaft sealing with o-rings bearing bush of brass sealing element of Buna CB black dissipative replaceable in the housing |
Contattaci per avere un'offerta per il prodotto DKZ103
Vendiamo solo prodotti ORIGINALI E NUOVI.
La nostra azienda non è un distributore autorizzato. Tutti i diritti sono riservati ai produttori e ai loro partner ufficiali.
