Marca | B & PLUS |
Prodotto | RXE-1805PPU-03 |
Descrizione | Sistema di sensori remoti |
Codice interno | PRT4625709 |
Specifiche tecniche | Trasmettitore applicabile RXT-1805PU, RST-1805PU, RAT-1805-PU Distanza operativa 0... 5 mm(Flush: 0... 4 mm) Offset centrale =< +/-2,5 mm Funzione di uscita PNP Tensione d'esercizio 24VDC +/ -10% Consumo di corrente =< 25mA Frequenza di commutazione 25Hz Temperatura di esercizio 0... +50° C Umidità operativa 35,,90% RH Temperatura di conservazione -25... +75deg.C. Umidità di conservazione 35,,90% RH Isolamento => 50 M Ohm (a 500 VM), da custodia a circuito Resistenza dielettrica 1000VAC/1 min. da custodia a circuito Classe di vibrazione 10... 55 Hz, ampiezza 1,5 mm 2 ore. ogni asse fino a x-y-z. Resistenza agli urti 50 G, 3 volte per asse rispetto a x-y-z, totale 18 volte. Classe di protezione IP67 Cavo PUR: Phi 5 mm/3x0,3 mm2 Materiale della cassa: ottone nichelato Materiale della superficie attiva Nylon12 |
Contattaci per avere un'offerta per il prodotto RXE-1805PPU-03 oppure per qualsiasi prodotto della B & PLUS .
Vendiamo solo prodotti ORIGINALI E NUOVI.
La nostra azienda non è un distributore autorizzato. Tutti i diritti sono riservati ai produttori e ai loro partner ufficiali.
